Scientists overcome major electrical bottleneck in next-generation semiconductors

South Korean researchers have deviced a viable means to resolve one of the largest obstacles limiting the next generation of computer chips.The shrinking of computer chips has exposed a stubborn problem.

Even when a semiconductor can carry electricity efficiently, getting that electricity into the material can waste power and slow the device down.

Now these researchers have demonstrated a possible way around the obstacle with a design that allows electrical current to move smoothly from a conductive region into a semiconducting region without crossing the conventional junction between two separate materials.

The team also directly mapped the movement of charges at the nanometer scale, providing experimental evidence that the new interface does not disrupt the current.

The advance could support the development of smaller and more energy-efficient electronics, including AI processors, low-power devices, and future logic chips.

The research was led by Professor Seungbum Hong of KAIST’s Department of Materials Science and Engineering, in collaboration with Professor Kibum Kang at KAIST and Professor Sung Beom Cho’s team at Sungkyunkwan University.

Modern transistors depend on metal electrodes to deliver electricity into a semiconductor. However, the boundary where those materials meet can resist the movement of electrical charges.

This contact resistance consumes energy, produces heat, and limits how much performance engineers can gain by making transistors smaller.

The problem is particularly important for two-dimensional semiconductors. These materials can be only one or a few atomic layers thick, making them attractive for electronics that may eventually need to operate at dimensions beyond the practical limits of conventional silicon.

Yet their extreme thinness also makes it difficult to create efficient electrical contacts without damaging or altering the semiconductor.

Instead of placing a separate metal electrode on top of the semiconductor, the researchers created conductive and semiconducting regions inside one continuous sheet of platinum diselenide (PtSe₂).

PtSe₂ is especially useful for this approach because its electronic behavior changes with thickness.Thicker regions can act as a semimetal, while thinner regions behave as a semiconductor.

This allows different electronic functions to be built from the same underlying material rather than joining two unrelated materials together.

The resulting structure was monolithic, meaning the PtSe₂ film continued across the boundary without a physical break. In principle, that seamless connection should give charges a more direct route into the semiconductor and avoid some of the resistance created by conventional metal contacts.

To test whether that was actually happening, the team used Atomic Force Microscopy (AFM).The technique moves an extremely fine probe across a surface to measure its physical and electrical properties at very small scales.

The researchers combined this approach with in-plane current detection, allowing them to map how charges traveled from the semimetallic section into the semiconducting section of the PtSe₂ film.

The study was published in the journal, Matter.The images showed that the current continued across the boundary without being blocked or forced away from its path.

According to the researchers, this is the first direct experimental demonstration that charge transport can remain uninterrupted across this type of monolithic semimetal-to-semiconductor interface.

The team also applied an electric field to the semiconducting region and successfully controlled the current passing through the device.

That result showed that the structure could do more than simply conduct electricity. It could also perform the switching function required in transistor-based electronics.
